Rating:3A 125VAC 1.5A 250VAC
Contact Resistance:50mΩ Max.(initial)
Insulation Resistance:100mΩMin
Operating Force:r 350±50gf
Total Travel:3.0±0.5mm
Operatong Life:50,000 Cycles Min
Solder specifications:260ofor5 seconds
Function:OFF-ON
Operating Temerature:-0℃~+85℃
